The HandySnap Deluxe Installation Package includes one of our premier snap installation tools, the HandySnap, along with a comprehensive assortment of snap fastener components in the standard marine size, known as a line 24 snap (5/8" button top diameter). The HandySnap tool is designed to optimize your workflow by punching the hole and setting the snap in a single operation, eliminating the need for pre-punching in most fabric or leather assemblies. Its adjustable compression knob, similar to the function of Vise-Grips, allows you to precisely control the applied pressure for secure, professional-quality results every time.

Selecting the appropriate snap components can significantly enhance the performance of your canvas or leather project. This package includes not only the most commonly used snap components but also those often overlooked yet essential types of snaps.

The most frequently used snap parts—the button, socket, stud, and eyelet—are all included. For thicker fabric assemblies (more than 6 layers of canvas), buttons with a 1/4" barrel are provided. This package also contains the less common, but vital, snap components. If you need to secure an additional fabric assembly to your single snap stud, this can be achieved with the included gypsy snaps and gypsy die. The gypsy snap is designed to attach cloth-to-cloth-to-cloth or cloth-to-cloth-to-surface assemblies to one snap stud. Additionally, if a locking snap is required, the package includes one-way or Pull-The-Dot snaps, which only unsnap from one side of the Pull-The-Dot snap stud. The special die for the Pull-The-Dot socket installation is included with the HandySnap tool.

This package includes:

• HandySnap Tool
• Button Die
• Socket Die (compatible with Pull-The-DOT®/one-way sockets)
• Stud Die
• Eyelet Die
• Gypsy Stud Die
• HandySnap Storage Case
• 20 DOT® Snap Fastener Button Silver 1/4" Barrel (#333010)
• 20 DOT® Snap Fastener Button Silver 11/64" Barrel (#333777)
• 40 Snap Fastener Normal Action Socket (#333050)
• 20 DOT® Snap Fastener Hard Action Socket (#333058)
• 10 DOT® Snap Fastener Screw Stud 3/8" (#333105)
• 20 Pull-The-DOT® Button (#555777)
• 20 Pull-The-DOT® Snap Socket (#555050)
• 40 DOT® Snap Fastener & Pull-the-DOT® Eyelet 1/4" (#333555)
• 10 Pull-The-DOT® Snap Screw Stud 3/8" (#555105)
• 10 Pull-The-DOT® Snap Cloth-to-Cloth Stud (#555100)
• 30 Snap Fastener Cloth-to-Cloth Standard Stud (#333100)
• 20 DOT® Snap Fasteners Gypsy Stud 3/16" Barrel (#333130)

The HandySnap Tool offers expanded functionality with a wide range of optional add-on die sets. With additional dies, you can install specialty fasteners and grommets such as Twist-Lock fasteners, Lift-The-DOT® eyelet-type studs, and multiple sizes of plain and spur grommets.

Available add-on dies include:

• Lift-The-DOT® Eyelet-Type Base Die Set (#106397)
• Turn Lock Die Set (#104993)
• #1 Hole Cutter Die 5/16" (#100908)
• #2 Hole Cutter Die 3/8" (#100909)
• 00 Plain Grommet Die 3/16" (#102894)
• #0 Plain Grommet Die 1/4" (#123588)
• #1 Plain Grommet Die 5/16" (#102452)
• #2 Plain Grommet Die 3/8" (#102213)
• #3 Plain Grommet Die 7/16" (#121601)
• #0 Spur Grommet Die 1/4" (#103629)
• #1 Spur Grommet Die 5/16" (#100971)
