SnapRite® Fastener Cloth-to-Cloth Set (Stainless Steel)
SKU: 104910
SnapRite® Fastener Cloth-to-Cloth Set (Stainless Steel)
SKU: 104910
Price per Pack
SnapRite Fastener Cloth-to-Cloth Set (Stainless Steel) is a complete snap fastener for cloth-to-cloth attachment that works with the Sailrite SnapRite System.
Description
SnapRite® Fastener Cloth-to-Cloth Set (Stainless Steel) is a complete snap fastener for cloth-to-cloth attachment that works with the Sailrite® SnapRite® System. The button rivets to the socket, and the eyelet rivets to the stud. The installed button and socket can then be snapped to the installed eyelet and stud. These marine snaps are made from 100% stainless steel and are highly resistant to corrosion.
The button in this set is specially designed with a hole in the top for use with the SnapRite System. The SnapRite System is a set of four unique dies that work with many standard rivet guns (we recommend the Professional Rivet Installation Tool, #103520) to install button, socket, stud and eyelet snap fastener components quickly and easily. The SnapRite Dies screw into the nosepiece of a rivet gun and must be used with a SnapRite Mandrel.
These fasteners are excellent for covers, cushions, dodgers and more.
Includes:
- SnapRite Snap Fastener Button 5/32” Barrel (#104153); Type 304 Stainless Steel
- Snap Fastener Normal Action Socket (#444050); Type 316 Stainless Steel
- Snap Fastener Standard Cloth-to-Cloth Stud (#444100); Type 316 Stainless Steel
- Snap Fastener Eyelet (#444555); Type 316 Stainless Steel
Specifications
| Brand | SnapRite |
|---|---|
| Color | Silver |
| Hardware Material | Stainless Steel Grade 304Stainless Steel Grade 316 |
| Size | Line 24, 0.600" |
Dimensions
| Button | |
|---|---|
| A. | 0.590" |
| B. | 0.136" |
| C. | 0.162" |
| Socket | |
|---|---|
| A. | 0.168" |
| B. | 0.168" |
| C. | 0.560" |
| Stud | |
|---|---|
| A. | 0.556" |
| B. | 0.395" |
| C. | 0.175" |
| D. | 0.175" |
| Eyelet | |
|---|---|
| A. | 0.161" |
| B. | 0.286" |
| C. | 0.566" |
